Installing and Configuring SNMP on CentOS for Server Monitoring

This guide demonstrates how to compile, install, and configure Net-SNMP on CentOS to enable server monitoring with services like 360 Monitoring. The steps are similar for other Linux distributions.

Compilation and Installation

Use the root account or an account with sudo privileges for installation to avoid permission issues.

1. Download the Source Code

Download a recent version of Net-SNMP. This example uses version 5.7.2 (check the Net-SNMP website for the latest stable release).

wget http://download.cloud.360.cn/yjk/net-snmp.tar.gz

If wget fails, download the file locally and upload it to your server.

2. Extract the Source Code

tar xzvf net-snmp.tar.gz

3. Configure Compilation Options

cd net-snmp-5.7.2
./configure --prefix=/usr/local/snmp --with-mib-modules=ucd-snmp/diskio --enable-mfd-rewrites

Configuration parameters explained:

• --prefix=/usr/local/snmp: Sets the installation directory.
• --with-mib-modules=ucd-snmp/diskio: Enables disk I/O monitoring support.
• --enable-mfd-rewrites: Allows new MFD rewrite modules for 64-bit counters, ensuring accurate network traffic data collection.

Note: During ./configure, you will be prompted to select SNMP protocol versions (1, 2c, 3). Version 1 is not recommended for security reasons. You can usually press Enter to accept the default options (including 2c and 3).

4. Compile and Install

make && make install

After installation, the SNMP daemon is located at /usr/local/snmp/sbin/snmpd. Configuration is required before starting the service.

Authentication Configuration

Exposing SNMP on the network is a security risk. Configure authentication to restrict access. 360 Monitoring supports SNMP v2c and v3 protocols; v3 is recommended for enhanced security.

SNMP v2c Configuration

v2c uses a community string (similar to a password) for authentication. Edit the configuration file (create it if it doesn't exist):

vim /usr/local/snmp/share/snmp/snmpd.conf

Add the following line:

rocommunity your_community_string default

Parameter explanation:

• rocommunity: Grants read-only access.
• your_community_string: Replace with a custom, complex string. Do not use the default public.
• default: Allows access from any IP. For better security, replace with the specific IP addresses of your monitoring servers. Example:

  rocommunity your_community_string 101.199.100.150
  rocommunity your_community_string 220.181.150.98
  # ... Add more monitoring node IPs as needed

After configuration, restart the snmpd service for changes to take effect.

SNMP v3 Configuration

v3 provides encrypted transmission for greater security. Edit the main configuration file:

vim /usr/local/snmp/share/snmp/snmpd.conf

Add a read-only user:

rouser your_username auth

Next, create the user. Edit (or create) the user configuration file:

vim /var/net-snmp/snmpd.conf

Add the following line (ensure the snmpd service is not running):

createUser your_username MD5 your_password

Notes:

• Customize your_username and your_password.
• The password must be at least 8 characters long.
• This configuration is automatically removed (converted to encrypted storage) after the first snmpd start and does not need to be re-added for subsequent restarts.

Start the SNMP Service

Start the service using the absolute path:

/usr/local/snmp/sbin/snmpd

To stop the service, use:

killall -9 snmpd

It is recommended to configure a system service (systemd or init) for automatic startup on boot, which is not covered in detail here.

(Optional) Enhance Security with a Firewall

If you are familiar with iptables, you can further restrict access sources. SNMP uses UDP port 161 by default. Example rules (assuming the external network interface is eth0; replace IPs with actual monitoring node IPs):

iptables -A INPUT -i eth0 -p udp -s 101.199.100.150 --dport 161 -j ACCEPT
iptables -A INPUT -i eth0 -p udp -s 220.181.150.98 --dport 161 -j ACCEPT
# ... Add other allowed IPs

Finally, set the default policy to DROP all other traffic to port 161. Be cautious, as incorrect firewall rules can make the service unavailable.

After completing these steps, you can add your server in 360 Monitoring, select the corresponding SNMP version (v2c or v3), and enter the configured community string or username/password to enable monitoring.
