Guide to iptables Firewall Configuration and Persistence on Debian/Ubuntu

Installing and Configuring iptables on Debian/Ubuntu

iptables may not be installed by default on Debian-based systems. To install it, use the following commands:

sudo apt update
sudo apt install iptables

Configuring iptables Rules

1. Clear Existing Rules

Before starting, clear all existing rules, user-defined chains, and reset counters.

sudo iptables -F
sudo iptables -X
sudo iptables -Z

2. Set Default Policies and Basic Rules

A secure starting point is to set the default policy to DROP and then open ports as needed. Below is a common basic rule set example:

# Set default policies
sudo iptables -P INPUT DROP
sudo iptables -P FORWARD DROP
sudo iptables -P OUTPUT ACCEPT

# Allow local loopback interface
sudo iptables -A INPUT -i lo -j ACCEPT

# Allow established/related connections
sudo iptables -A INPUT -m state --state ESTABLISHED,RELATED -j ACCEPT

# Allow SSH (port 22)
sudo iptables -A INPUT -p tcp --dport 22 -j ACCEPT

# Allow HTTP (80) and HTTPS (443)
sudo iptables -A INPUT -p tcp --dport 80 -j ACCEPT
sudo iptables -A INPUT -p tcp --dport 443 -j ACCEPT

# Allow local MySQL (3306), block external
sudo iptables -A INPUT -p tcp -s 127.0.0.1 --dport 3306 -j ACCEPT
sudo iptables -A INPUT -p tcp --dport 3306 -j DROP

# Allow ICMP (ping)
sudo iptables -A INPUT -p icmp -m icmp --icmp-type 8 -j ACCEPT

3. Rule Management Operations

View Rules:

# List all rules
sudo iptables -L -n
# List with line numbers
sudo iptables -L -n --line-numbers

Delete a Rule: For example, delete rule number 3 in the INPUT chain.

sudo iptables -D INPUT 3

Block IP Addresses:

# Block a single IP
sudo iptables -I INPUT -s 123.45.6.7 -j DROP
# Block a /24 subnet
sudo iptables -I INPUT -s 123.45.6.0/24 -j DROP

Persisting iptables Rules

Rules configured via command line are lost on reboot. To make them permanent, you must save them.

Method 1: Using iptables-persistent (Recommended)

This is the simplest method for Debian/Ubuntu.

Install the tool:

sudo apt install iptables-persistent

During installation, you will be prompted to save current rules.

Manually Save and Reload Rules:

# Save current rules
sudo netfilter-persistent save
# Reload saved rules
sudo netfilter-persistent reload

Rule File Locations: Saved rules are stored here and loaded automatically at boot.

/etc/iptables/rules.v4  # IPv4 rules
/etc/iptables/rules.v6  # IPv6 rules

Method 2: Manual Save and Restore

Save rules to file:

sudo iptables-save > /etc/iptables/rules.v4
sudo ip6tables-save > /etc/iptables/rules.v6

Restore rules at boot: You can create a systemd service or add commands to /etc/rc.local.

# Restore IPv4 rules
iptables-restore < /etc/iptables/rules.v4
# Restore IPv6 rules
ip6tables-restore < /etc/iptables/rules.v6

Important Notes

• Proceed with Caution: When configuring a firewall on a remote server, always allow SSH (port 22) traffic before setting a default DROP policy to avoid locking yourself out. Consider creating a backup script first.
• Rule Order: iptables rules are matched sequentially. Pay attention when using -I (insert) and -A (append).
• Modern Alternative: For newer Debian versions (e.g., Debian 10+), consider nftables as the successor to iptables, offering more powerful features and a unified framework.
